Key Specifications:
• Sensitivity: 8.0 mV/µm (±5%)
• Measurement Range: 0-2.0mm (2000µm)
• Frequency Response: DC to 10kHz
• Temp Range: -40°C to +200°C (peak 250°C)

Extreme-Environment Design:
✓ 11mm heavy-duty probe
✓ M14×1.5 threaded mounting
✓ 6MPa pressure rating
✓ 25g vibration resistance
✓ Optional IP68 protection

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 0.6-1.4mm

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• High-temp mineral-insulated cable
• ATEX/IECEx options available

Typical Applications:

Gas turbine hot section monitoring

Nuclear plant rotating equipment

Ultra-high-pressure steam turbines

Key Features:
• Multi-Parameter Monitoring:
✓ Vibration (velocity/displacement)
✓ Shaft position
✓ Speed/RPM
✓ Temperature
• Advanced Diagnostics: Real-time FFT/waveform analysis
• Scalable Architecture: Expandable channel capacity

Technical Specifications:

Input Channels: 16 fully configurable

Sensor Compatibility:
• Eddy current probes (PR642x/PR9268)
• Velocity sensors (4-20mA/0-10V)
• IEPE accelerometers
• Tachometer inputs

Accuracy: ±0.5% FS

Sampling Rate: 1kHz/channel

System Integration:
✓ 16x isolated 4-20mA outputs
✓ 32 programmable alarm relays
✓ Ethernet + Modbus RTU + OPC UA
✓ Redundant power supply option

Industrial Design:

Rack-mounted (IP20)

-20°C to +70°C operation

19" standard cabinet installation

Typical Applications:

Power plant turbine monitoring

Offshore compressor trains

Large rotating equipment arrays

Compliance:
API 670, ISO 10816, CE, UL

Special Capabilities:

Predictive maintenance analytics

Remote monitoring via OPC UA

Customizable alarm strategies

Key Specifications:
• Measurement Range: 0-20 mm/s RMS
• Frequency Range: 10Hz-1kHz (ISO 10816 compliant)
• Accuracy: ±1% FS
• Output: 4-20mA (isolated)

I/O Configuration:
✓ 1x velocity sensor input
✓ 2x alarm relays (SPDT)
✓ LED status indicators

Electrical & Mechanical:

Power: 24V DC (±10%)

Operating Temp: -20°C to +70°C

Protection: IP40

Mounting: DIN-rail

Setup & Operation:
• DIP switch configuration (no software needed)
• Plug-and-play installation

Typical Applications:

Pump/motor vibration monitoring

Fan/blower protection

Standalone equipment guarding

Compliance:
ISO 10816, CE, UL

Special Features:

Compact, cost-effective solution

Easy to install and maintain

No external power required for sensors

Key Specifications:
• Sensitivity: 10.0 mV/µm (±5%)
• Measurement Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Temp Range: -40°C to +175°C (peak 200°C)

Extreme-Environment Design:
✓ 11mm ruggedized probe
✓ M14×1.5 threaded mounting
✓ 6MPa pressure rating
✓ 25g vibration resistance
✓ Optional IP68 protection

Measurement Performance:

Target: AISI 4140 steel

Linear range: 0.3-0.7mm

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• High-temp mineral-insulated cable
• ATEX/IECEx options available

Typical Applications:

Gas turbine hot section monitoring

Steam turbine high-pressure stages

Offshore compressor protection

Key Specifications:
• Sensitivity: 8.0 mV/µm (±5%)
• Measurement Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Robust Design:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ -30°C to +120°C operation
✓ 20g vibration resistance
✓ 4MPa pressure rating

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 0.3-0.7mm (60% of full scale)

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Turbine shaft vibration monitoring

Compressor thrust position measurement

Industrial pump/fan protection

Compliance:
Meets API 670 and ISO 10816 standards

Special Features:

Reliable performance in harsh industrial environments

Standard configuration for general monitoring applications

Easy installation and maintenance

Key Specifications:
• Sensitivity: 4.0 mV/µm (±5%)
• Measurement Range: 0-2.0mm (2000µm)
• Frequency Response: DC to 10kHz
• Temp Range: -40°C to +200°C (peak 250°C)

High-Temp Design Features:
✓ 8mm high-temperature probe
✓ M10×1 threaded mounting
✓ Mineral-insulated cable (5m standard)
✓ 20g vibration resistance
✓ 4MPa pressure rating

Measurement Performance:

Target: AISI 4140 steel

Linear range: 0.6-1.4mm

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• Requires high-temp cabling
• API 670 compliant

Typical Applications:

Gas turbine hot section monitoring

Steam turbine shaft vibration

High-temperature compressor trains

Key Specifications:
• Sensitivity: 8.0 mV/µm (±5%)
• Measurement Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Robust Design:
✓ 8mm probe diameter
✓ M10×1 threaded mounting
✓ -30°C to +120°C operation
✓ 20g vibration resistance
✓ IP67 protection (optional)

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 0.3-0.7mm

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Turbine/compressor shaft monitoring

Pump and fan bearing protection

General industrial machinery

Compliance:
Meets API 670 and ISO 10816 standards

Special Features:

/011 variant features enhanced sealing

Reliable performance in harsh conditions

Easy installation and maintenance

Core Function:
High-temperature eddy current sensor designed for extreme environment displacement monitoring in critical rotating equipment.

Key Specifications:
• Sensitivity: 8.0 mV/µm (±5%)
• Measurement Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Temperature Range: -40°C to +200°C (peak 250°C)

High-Temp Design Features:
✓ 8mm high-temperature probe
✓ M10×1 threaded mounting
✓ Mineral-insulated cable (5m standard)
✓ 20g vibration resistance
✓ 4MPa pressure rating

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 0.3-0.7mm (60% of full scale)

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• Special high-temp cable required
• API 670 compliant

Typical Applications:

Gas turbine hot section monitoring

Steam turbine high-temperature zones

Petrochemical compressor trains

Key Specifications:
• Sensitivity: 8.0 mV/µm (±5%)
• Measurement Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Mechanical Design:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ Operating temperature: -30°C to +120°C
✓ Vibration resistance: 20g (50Hz)

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 0.3-0.7mm (60% of full scale)

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 monitoring systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Turbine shaft vibration monitoring

Compressor thrust position measurement

Industrial pump/fan protection

Compliance:
Meets API 670 machinery protection standards

Special Features:

Optimized for standard-range displacement measurements

Rugged industrial construction

Reliable performance in harsh environments

Core Function:
Industrial eddy current sensor for wide-range displacement monitoring in heavy rotating equipment.

Key Specifications:
• Sensitivity: 1.4 mV/µm (±5%)
• Extended Range: 0-14mm (14,000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Mechanical Configuration:
✓ 8mm diameter probe
✓ M10×1 threaded mounting
✓ -30°C to +120°C operation
✓ 20g vibration resistance

Measurement Performance:

Target material: AISI 4140 steel

Linear range: 4.2-9.8mm (60% of full scale)

Typical accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Special Features:

Optimized for large clearance applications

Maintains stability in high-vibration environments

Wide linear measurement range

Typical Applications:

Large turbine shaft monitoring

Heavy compressor axial displacement

Industrial machinery with wide gaps

Compliance:
Meets API 670 machinery protection standards
