The Weidmüller IE-PS-RJ45-FH-BK is a Cat.6A / Class EA RJ45 plug designed for fast, tool-less field termination using IDC (Insulation Displacement Connection) technology. It features a 360° shielded, zinc die-cast metal housing for robust protection against electromagnetic interference.

Engineered for seamless integration into industrial control systems, this power supply ensures optimal performance and reliability, delivering precise voltage regulation and high efficiency.

Core Function:
High-sensitivity eddy current sensor for precision displacement monitoring in critical rotating equipment.

Key Specifications:
• Sensitivity: 10.0 mV/µm (±5%)
• Measurement Range: 0-1.0mm (1000µm)
• Frequency Response: DC to 10kHz
• Output: -2 to -20V DC linear signal

Robust Design:
✓ 11mm heavy-duty probe
✓ M14×1.5 threaded mounting
✓ -40°C to +120°C operation
✓ 20g vibration resistance
✓ 4MPa pressure rating

Measurement Performance:

Target: AISI 4140 steel

Linear range: 60% of full scale

Accuracy: ±1% FS

System Integration:
• Compatible with EPRO MMS6000 systems
• Standard 5m/9m cable options
• CON021 quick-disconnect available

Typical Applications:

Turbine shaft vibration monitoring

Compressor thrust position measurement

Precision bearing clearance monitoring

Special Features:

/207 variant optimized for high-sensitivity applications

Enhanced signal resolution for critical measurements

Industrial-grade durability

Compliance:
Meets API 670 machinery protection standards
