Specifications: Models: D (Double-Acting), DA (Spring-Return) Type: Piston Actuator, Scotch-Yoke design Action: Double-Acting (D) / Spring-Return (DA) Standard Travel: 90° quarter-turn (standard), 180° available for the D model. Mounting: Directly onto standard ISO 5211 mounting pads. Air Supply & Performance: Air Supply Pressure Range: D (Double-Acting): 2.8 to 8.6 bar (40 to 125 psig) DA (Spring-Return): 3.4 to 8.6 bar (50 to 125 psig) [Air pressure must overcome spring force] Ambient Temperature Range: -20° to 85°C (-4° to 185°F) with standard lubricant. Stroking Speed: Very fast, typically 1-2 seconds for 90° travel, depending on air supply and piping. Torque Output: Output: Torque output is a function of air supply pressure and actuator size. The DA model's torque varies between the air-side and spring-side of the stroke. Example Torque (for Size 30 @ 6.9 bar/100 psig): D Actuator: Approximately 70 Nm (50 lb-ft) at both ends of the stroke. DA Actuator: ~100 Nm (75 lb-ft) on the air end, ~60 Nm (45 lb-ft) on the spring end. Physical Data (Typical for Size 30): Body Material: Hard Anodized Aluminum Piston Rod & Yoke: Hardened Steel Weight: Approximately 5.4 kg (12 lbs) for the DA model. Accessories & Options: Positioners: Fisher FIELDVUE™ DVC6000 or other digital positioners can be mounted for precise modulating control. Limit Switches: Proximity or mechanical switches to indicate valve position. Solenoid Valves: Used for direct electrical control, essential for on-off and ESD applications. Air Filter Regulators: To clean and regulate the air supply. Manual Override: Optional handwheel for manual operation.

The Allen-Bradley 1394-AM04 Digital Input Module is designed for use in ControlLogix systems. It provides reliable digital input capabilities for monitoring and controlling various industrial processes.

The EMERSON VE4003S2B6 is an advanced DeltaV System designed for seamless integration into complex industrial control environments. It offers high-performance, reliability, and ease of operation, ideal for optimizing production processes across various industries.
