The Schneider Electric Masterpact MVS 12N 3F205 is a low-voltage air circuit breaker (ACB) designed for fixed mounting in electrical distribution systems. As part of the Masterpact MVS range, it provides essential circuit protection for industrial and commercial applications.

The ABB 3HAC3180-1 DCS Module is an advanced Digital Control System module designed for precise control and monitoring in industrial automation applications. It leverages cutting-edge technology to enhance operational efficiency and reliability in various industrial settings.

Key Parameters Item Specification / Description Valve Type Electro-proportional flow control cartridge valve (poppet type) Style / Orientation B style — side-in, nose-out Function (de-energized) Port-to-port flow blocked (normally closed) Function (energized) Flow allowed, rate proportional to coil current Cartridge / Cavity NG16, cavity C-16-3S Maximum Working Pressure 280 bar Rated Flow Capacity 0–160 L/min Operating Fluid Anti-wear hydraulic oils; standard Buna-N seals, Viton optional Fluid Viscosity Range 10–800 cSt Operating Temperature Range –30 °C to +90 °C Internal Leakage (max) ≤ 10 cm³/min at 140 bar Coil Supply Voltage 24 V DC Coil Current for Max Flow ~0.7 A @ 24 V DC Recommended Filtration 15/13/11 (high pressure) or 17/15/12 (lower pressure)
