Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series XC Series Programmable Controllers Product Model XC-CPU101-C256K Product Type PLC Central Processing Unit (CPU) Program Memory 256 KB Data Memory Integrated (typically a portion of the 256 KB is allocated) Integrated Communication Ports • 1 x Ethernet (XC-BUS) • 1 x RS-232 (for programming or other devices) • 1 x RS-485 (for Modbus master/slave, etc.) Integrated Real-Time Clock (RTC) Yes I/O Expansion Capability Yes, via XC series extension modules on the right side Max. Number of Connected I/O Modules Up to 8 (including special function modules) Programming Software Eaton XSoft-CODESYS (based on CODESYS V3) Programming Languages Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC) Supported Communication Protocols Modbus TCP (via Ethernet), Modbus RTU (via RS-232/485), XC-BUS (for I/O expansion) Power Supply 24 V DC (via the base unit or a separate power supply module) Approvals / Certifications CE, cULus, RoHS

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model C445BD-SDNM Product Type Electromechanical Contactor Number of Main Poles 4 Rated Operational Current (Iₑ) at AC-3 55 A (at 690V AC) Rated Thermal Current (Ith) 80 A Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Control Coil Voltage DC (Specific voltage is denoted by the suffix, e.g., C445BD-S24 for 24V DC. "SDNM" often indicates a standard version, and the exact voltage must be specified when ordering). Motor Rating (AC-3) at 400V ~ 55 kW Motor Rating (AC-3) at 690V ~ 75 kW Electrical Life > 1 Million operations (under specific load conditions) Mechanical Life > 10 Million operations Auxiliary Contacts Not included as standard; add-on blocks available (e.g., CA4... series) Mounting Snap-on mounting to standard DIN Rail (35mm) or screw mounting Approvals / Certifications CE, cULus, CCC, IEC/EN 60947-4-1

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Model DILM32-XTEE11 Catalog Reference RAC240 Product Type Contactor Relay (4-pole, changeover contacts) Number of Contacts 4 Contact Type 4 Changeover (CO) / Form C (Each contact: 1 NO + 1 NC) Rated Operational Current (Iₑ) 10 A (at 250V AC) Rated Thermal Current (Ith) 16 A Rated Insulation Voltage (Ui) 500 V AC Control Coil Voltage 24 V DC Special Feature Latching (Impulse) Version (Mechanically held) Electrical Life > 1 x 10⁶ operations Mechanical Life > 10 x 10⁶ operations Mounting 35 mm DIN Rail Terminal Type Cage Clamp (Spring-loaded) Approvals / Certifications CE, cULus, CCC, IEC/EN 60947-5-1

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series ED6 Product Model ED6-10/1N/D/003 Product Type Type 2 / Class II Surge Protective Device (SPD) Rated Voltage 230/400 V AC Nominal System Voltage 230 V AC (Single-Phase + N) Protection Mode 1-Pole + N (L-N, N-PE) Max. Discharge Current (Imax - 8/20 µs) 10 kA per pole Nominal Discharge Current (In - 8/20 µs) 5 kA Voltage Protection Level (Up) ≤ 1.5 kV Response Time < 25 ns Backup Fuse Recommendation 16 A gG/gL (or according to local regulations) Status Indication Visual (Green: OK; Red: End-of-Life) & Remote Signalling Contact Remote Contact 1 Changeover Contact (SPDT) Mounting 35 mm DIN Rail (EN 60715) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series PXK Product Model PXK-B16/1N/003-A Product Type Type 2 / Class II Surge Protective Device (SPD) Rated Voltage (Uc) 230/400 V AC Nominal System Voltage 230 V AC (Single-Phase + N) Protection Mode 1-Pole + N (L-PE, N-PE) Max. Discharge Current (Imax - 8/20 µs) 16 kA per mode Nominal Discharge Current (In - 8/20 µs) 8 kA Voltage Protection Level (Up) ≤ 1.5 kV Response Time < 25 ns Backup Overcurrent Protection (Recommended) 16 A to 63 A gG/gL (or per local regulations) Status Indication Visual Indicator (Green: OK; Red: End-of-Life) Remote Signalling Contact 1 Changeover Contact (SPDT) Mounting 35 mm DIN Rail (EN 60715) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series PFIM Product Model PFIM-40/4/003 Product Type Type 1 + Type 2 Combined SPD Rated Voltage (Uc) 230/400 V AC Nominal System Voltage 400 V AC (Three-Phase + N) Protection Mode 3-Poles + Neutral (3P+N) (L1-PE, L2-PE, L3-PE, N-PE) Lightning Impulse Current (Iimp - 10/350 µs) 20 kA per pole Max. Discharge Current (Imax - 8/20 µs) 40 kA per pole Voltage Protection Level (Up) ≤ 2.5 kV Response Time < 100 ns Backup Overcurrent Protection Required (specific rating per local regulations and installation manual) Status Indication Visual Indicator (Green: OK; Red: End-of-Life) Remote Signalling Contact 1 Changeover Contact (SPDT) Special Feature Thermal Disconnector Mounting Mounting Plate (for panel mounting) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series PLD9 Product Model PLD9-10/1N/C/003 Product Type Type 2 / Class II Surge Protective Device (SPD) Rated Voltage (Uc) 230/400 V AC Nominal System Voltage 230 V AC (Single-Phase + N) Protection Mode 1-Pole + N (L-PE, N-PE) Max. Discharge Current (Imax - 8/20 µs) 10 kA per mode Nominal Discharge Current (In - 8/20 µs) 5 kA Voltage Protection Level (Up) ≤ 1.5 kV Response Time < 25 ns Backup Overcurrent Protection (Recommended) 16 A gG/gL (or per local regulations) Status Indication Visual Indicator (Green: OK; Red: End-of-Life) Remote Signalling Contact 1 Changeover Contact (SPDT) Mounting 35 mm DIN Rail (EN 60715) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series PLD9 Product Model PLD9-C20 Product Type Type 2 / Class II Surge Protective Device (SPD) Rated Voltage (Uc) 230/400 V AC Nominal System Voltage 230 V AC (Single-Phase) Protection Mode 1-Pole (L-PE) Max. Discharge Current (Imax - 8/20 µs) 20 kA Nominal Discharge Current (In - 8/20 µs) 10 kA Voltage Protection Level (Up) ≤ 1.5 kV Response Time < 25 ns Backup Overcurrent Protection (Recommended) 16 A gG/gL (or per local regulations) Status Indication Visual Indicator (Green: OK; Red: End-of-Life) Remote Signalling Contact Not Available Mounting 35 mm DIN Rail (EN 60715) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series PF1M Product Model PF1M-63/4/003 Product Type Type 1 + Type 2 Combined SPD Rated Voltage (Uc) 230/400 V AC Nominal System Voltage 400 V AC (Three-Phase + N) Protection Mode 3-Poles + Neutral (3P+N) (L1-PE, L2-PE, L3-PE, N-PE) Lightning Impulse Current (Iimp - 10/350 µs) 25 kA per pole Max. Discharge Current (Imax - 8/20 µs) 63 kA per pole Voltage Protection Level (Up) ≤ 2.5 kV Response Time < 100 ns Backup Overcurrent Protection Required (specific rating per local regulations and installation manual) Status Indication Visual Indicator (Green: OK; Red: End-of-Life) Remote Signalling Contact 1 Changeover Contact (SPDT) Special Feature Thermal Disconnector Mounting Mounting Plate (for panel mounting) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11

Technical Parameters Parameter Category Specification / Value Brand Eaton Product Series PF1M Product Model PF1M-25/2/003 Product Type Type 1 + Type 2 Combined SPD Rated Voltage (Uc) 230/400 V AC Nominal System Voltage 230 V AC (Single-Phase + N) Protection Mode 1-Pole + Neutral (1P+N) (L-PE, N-PE) Lightning Impulse Current (Iimp - 10/350 µs) 12.5 kA per pole Max. Discharge Current (Imax - 8/20 µs) 25 kA per pole Voltage Protection Level (Up) ≤ 2.0 kV Response Time < 100 ns Backup Overcurrent Protection Required (specific rating per local regulations and installation manual) Status Indication Visual Indicator (Green: OK; Red: End-of-Life) Remote Signalling Contact 1 Changeover Contact (SPDT) Special Feature Thermal Disconnector Mounting Mounting Plate (for panel mounting) Connection Screw Terminal Approvals / Certifications CE, IEC 61643-11
