Parameter Specification Product Series Eaton DS7 Model Number DS7-340SX041N0-N Description Soft Starter with Bypass, 340A Frame, 41A, 22kW, 400V Rated Supply Voltage 400V AC, 50/60 Hz (3 Phase) Frame Size 340A Set Current / Max. Current 41 A (Adjustable within the frame's range) Motor Power Rating 22 kW (30 HP) @ 400V Control Supply Voltage 100-250V AC (as set by "SX" code) Integrated Bypass Yes (Internal Bypass Contactor) Keypad Standard Keypad (Not the advanced LCD version) Start Control Voltage ramp, Current limit Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating Communication Optional communication modules (e.g., Profibus DP, DeviceNet, Modbus RTU) Enclosure Rating IP00 (Open Type, must be installed in a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton PowerXL DG1 (S801 Line) Model Number S801+R13N3S Description Variable Frequency Drive, 28A, 15kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 28 A Motor Power Rating 15 kW (20 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features EMC Filter (Standard), Basic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton DS7 Model Number DS7-340SX160N0-N Description Soft Starter with Bypass, 340A Frame, 160A, 110kW, 400V Rated Supply Voltage 400V AC, 50/60 Hz (3 Phase) Frame Size 340A Set Current / Max. Current 160 A (Adjustable within the frame's range) Motor Power Rating 110 kW (150 HP) @ 400V Control Supply Voltage 100-250V AC (as set by "SX" code) Integrated Bypass Yes (Internal Bypass Contactor) Keypad Standard Keypad (Not the advanced LCD version) Start Control Voltage ramp, Current limit Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating Communication Optional communication modules (e.g., Profibus DP, DeviceNet, Modbus RTU) Enclosure Rating IP00 (Open Type, must be installed in a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+N66N3S Description Variable Frequency Drive, 128A, 75kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 128 A Motor Power Rating 75 kW (100 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton CPY C3 Series Model Number CPY-C3-AAL41-HD Description Definite Purpose Contactor, 3-Pole, 40A, Heavy Duty Rated Load 40 Amps Poles 3 Rated Voltage 240V AC / 480V AC / 600V AC Rated Load (at 240V AC) Inductive (AC-3 - Motor): 25 HP Resistive (AC-1): 40A Coil Voltage 240V AC (This is a critical part of the model number "AAL*41*") Terminals Screw Terminals (for both power and coil) Electrical Life Higher than standard duty models, suitable for frequent switching (e.g., 500,000+ mechanical operations, 100,000+ electrical at rated load). Mounting DIN Rail or Panel Mount Agency Approvals UL 508, CSA C22.2 No. 14, CE

Parameter Specification Product Series Eaton CPY C3 Series Model Number CPY-C3-ADV151 Description Definite Purpose Contactor, 2-Pole, 30A Rated Load 30 Amps Poles 2 Rated Voltage 240V AC / 480V AC Rated Load (at 240V AC) Resistive: 30A Inductive (AC-3 - Motor): 25 HP Inductive (AC-1): 30A Ballast (Lighting): 20A Coil Voltage 24V AC (This is a critical part of the model number "ADV*151*") Terminals Screw Terminals (for both power and coil) Mechanical Life Typically 1-2 million operations Electrical Life Typically 100,000 - 200,000 operations at rated load Mounting DIN Rail or Panel Mount Agency Approvals UL 508, CSA C22.2 No. 14, CE

Parameter Specification Product Series Eaton DS7 Model Number DS7-340SX070NO-L Description Soft Starter with Bypass, 340A, 250kW, 400V, 24V Control, LCD Keypad Rated Supply Voltage 400V AC, 50/60 Hz (3 Phase) Motor Power Rating 250 kW (355 HP) @ 400V Rated Current 340 A Current Range Adjustable Control Supply Voltage 24V AC/DC (as set by "SX" code) Integrated Bypass Yes (Internal Bypass Contactor) Keypad Advanced LCD Display (as denoted by -L) Start Control Voltage ramp, Current limit, Torque control Protection Features Overload, Phase Loss, Phase Imbalance, Locked Rotor, Overheating, Undercurrent Communication Optional communication modules (e.g., Profibus DP, DeviceNet, Modbus RTU) Enclosure Rating IP00 (Open Type, must be installed in a control panel) Standards & Certifications CE, cULus, RoHS

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+T24P3S Description Variable Frequency Drive, 24A, 7.5kW, 240V Rated Input Voltage 200 - 240V AC, ±10%, 3-Phase, 50/60 Hz Rated Output Current 24 A Motor Power Rating 7.5 kW (10 HP) @ 240V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control Integrated Features EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS

Parameter / Specification Description Product Type Replacement Control Printed Circuit Board (PCB) Model Number PCB-DS7-200A-CONTROL-V05 Compatible With Eaton DS7 Series Soft Starters, 200A Frame Size Core Function Executes soft start/stop control logic, provides motor protection, and handles user interface. Protected Functions Typically includes overload, phase loss, phase imbalance, locked rotor, and over-temperature protection. User Interface Connects to and controls the DS7 soft starter's built-in keypad and display. Control Connections Manages the control wiring terminals for Run/Stop, fault reset, relay outputs, etc. Firmware Comes pre-loaded with the operating firmware for the soft starter. Usage Spare part for repair and maintenance. Must be installed by a qualified technician.

Parameter Specification Product Series Eaton PowerXL DG1 (S811 Line) Model Number S811+T30N3S Description Variable Frequency Drive, 59A, 30kW, 400V Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz Rated Output Current 59 A Motor Power Rating 30 kW (40 HP) @ 400V Overload Capacity 150% of rated current for 60 seconds Control Methods V/F Control, Sensorless Vector Control, Closed Loop Vector Control (with encoder option) Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad Digital Inputs 4 (programmable) Digital Outputs 2 (1 relay, 1 transistor) Analog Inputs 2 (0/4-20mA or 0-10V, programmable) Analog Output 1 (0/4-20mA or 0-10V, programmable) Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET) Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel) Standards & Certifications CE, cULus, RoHS
