Parameter Specification Product Model MTL5531 Product Line Eaton MTL5500+ Series Function Single-channel 2-wire transmitter isolator & power supply Input Signal 4-20 mA from hazardous-area transmitters Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Intrinsic Safety (IS) Certification ATEX, IECEx, FM, CSA Line Fault Detection Open/short circuit detection Accuracy ±0.1% of span Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C

Parameter Specification Product Model NZM1-XMV Product Line Eaton NZM MCCB Series Rated Operational Current Up to 63 A (frame-dependent) Rated Voltage 690 V AC Number of Poles 3 Poles Trip Unit Type Thermal-magnetic with motor protection curve Breaking Capacity 25 kA (at 400 V AC, typical) Auxiliary Contacts 1 NO + 1 NC (included) Shunt Release Included (for remote tripping) Mounting Fixed or plug-in Standards Compliance IEC 60947-2, UL 489

Parameter Specification Product Model HI11-P1/P3/E Product Type Mechanical Interlock Kit Compatibility Eaton contactors (e.g., DILA, DILM series) with 1-pole and 3-pole configurations Material Reinforced thermoplastic or metal Mounting Direct attachment to contactors Safety Standard IEC 60947-1, ISO 13849-1 (as part of safety system)

Parameter Specification Product Model 6026077-001 Product Type Contactor Coil Rated Voltage Example: 24 V DC (MUST verify for this specific part) Power Consumption Example: 8 W (typical, depends on voltage) Compatible Contactors Specific Eaton contactor models (e.g., certain DILM series) Electrical Insulation Class F or higher (typical) Operating Temperature -25°C to +60°C (ambient)

Parameter Specification Product Model FCV7-10-C-0-FF Product Line Eaton Hydraulic Flow Control Valves Rated Flow Capacity Up to 60 L/min (15.85 GPM) Maximum Operating Pressure 350 bar (5,000 psi) Pressure Compensation Range 10–350 bar (145–5,000 psi) Port Size SAE 3/4" (e.g., SAE-12) Valve Type Pressure-compensated, pilot-operated Function Metered flow in one direction, free flow in reverse Leakage Minimal internal leakage (meets ISO standards) Operating Temperature -40°C to +100°C (hydraulic fluid) Fluid Compatibility Mineral oil, synthetic fluids (ISO VG 32-68)

Parameter Specification Product Model MTL5043 Product Line Eaton MTL5000 Series Signal Conditioners Function Single-channel signal isolator & converter Input Signal 4-20 mA Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Accuracy ±0.1% of span Line Fault Detection Configurable for open/short circuit indication Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C Compliance & Certifications CE, ATEX (for non-hazardous areas [Ex n])

Parameter Specification Product Model MTL5546 Product Line Eaton MTL5500+ Series Function Single-channel 2-wire transmitter isolator & power supply Input Signal 4-20 mA from hazardous-area transmitters Output Signal Isolated 4-20 mA Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Intrinsic Safety (IS) Certification ATEX, IECEx, FM, CSA Line Fault Detection Open/short circuit detection Accuracy ±0.1% of span Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C

Parameter Specification Product Model EMPDT1H1C2 Product Line Eaton EMP Series Timer Relays Supply Voltage 24–240 V AC/DC (wide range) Timing Range 0.1 sec – 100 hours (adjustable) Output Contacts 1 CO (Changeover) Contact Rating 8 A at 250 V AC Accuracy ±0.5% of set time + 10 ms Display Digital LCD with status LEDs Mounting DIN-rail (35 mm) Operating Temperature -20°C to +55°C Protection Rating IP50 (front panel) Standards Compliance UL 508, IEC 61812-1

Parameter Specification Product Model 9122-IS Product Line Eaton Pressure Transmitters Measurement Type Gauge, absolute, or sealed gauge pressure Pressure Range Selectable (e.g., 0–100 bar) Output Signal 4–20 mA (2-wire) Intrinsic Safety (IS) Certification ATEX, IECEx (Entity Parameters: e.g., Vmax = 30 V, Imax = 100 mA) Accuracy ±0.25% of span (typical) Process Connection 1/2" NPT or G1/2 Electrical Connection 1/2" NPT conduit Housing Material 316 stainless steel Operating Temperature -40°C to +85°C (environment) Protection Rating IP67

Parameter Specification Product Model MTL5544D Product Line Eaton MTL5500+ Series Function Single-channel 2-wire transmitter isolator with dual outputs/diagnostics Input Signal 4-20 mA from hazardous-area transmitters Output Signal Dual isolated 4-20 mA (or configurable outputs) Power Supply 20-30 V DC Isolation Galvanic isolation (input/output/power, typically 1.5 kV AC) Intrinsic Safety (IS) Certification ATEX, IECEx, FM, CSA Line Fault Detection Open/short circuit detection with detailed diagnostics Accuracy ±0.1% of span Mounting DIN-rail (35 mm) Operating Temperature -20°C to +60°C
