Technical Parameters Parameter Category Description / Value Brand & Series Eaton, AGM2 Series Model Number AGM2-11-PKZ2 Rated Operational Current (Ie) Specific value corresponding to "11" (e.g., likely a lower current rating such as 1.0 - 1.6A or similar). Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Utilization Category AC-3 (Squirrel cage motors: Starting, switching off during running) Motor Power Rating (at 400V AC) Specific kW/HP rating based on the "11" current code (e.g., ~0.55 kW / 0.75 HP). Short-Circuit Breaking Capacity (Icu) Typically 6 kA or higher at 400V AC (Confirm with datasheet) Trip Class Class 10 Operation Type Manual (Toggle Handle) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-4-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, ZB Series Model Number ZB32C-6 Output Voltage 6V DC Rated Output Power 32 W Rated Output Current 5.33 A Input Voltage Range 85-264V AC (Wide range, auto-sensing) Input Frequency Range 47-63 Hz Efficiency Typically >85% Power Factor (PF) Typically >0.9 Output Adjustment Range Typically ±10% (e.g., 5.4-6.6V DC) Mounting DIN Rail (35mm) Protection Overload Protection, Overvoltage Protection, Short-Circuit Protection Standards Compliance IEC/EN 61347-1, IEC/EN 61347-2-13, UL 1310, CSA C22.2 No. 223

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PKZMC Series Model Number PKZMC-0.16 Rated Operational Current (Ie) 0.16 A Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Utilization Category AC-3 (Squirrel cage motors: Starting, switching off during running) Motor Power Rating (at 400V AC) ~0.06 kW / 0.08 HP (Approximate) Short-Circuit Breaking Capacity (Icu) Typically 6 kA or higher at 400V AC (Confirm with datasheet) Trip Class Class 10 Operation Type Manual (Toggle Handle) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-4-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, CI Series (Control Interface) for PKZ0 System Model Number CI-K2-PKZ0-GR Compatibility PKZ0 motor starter system Function K2 - Specific control function (e.g., specific relay configuration, interface type). Color GR - Gray Rated Operational Voltage (Ue) Dependent on internal relay/electronics (e.g., 24V DC, 230V AC). Contact Configuration Specific to the K2 function (e.g., may contain relays with NO/NC contacts). Mounting DIN Rail (35mm), typically mounts adjacent to or integrated with the PKZ0 starter. Standards Compliance Relevant parts of IEC/EN 60947 series (e.g., -4-1, -5-1).

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NHI Series Model Number NHI11-PKZ0 Poles 3-Pole Trip Class Class 10 Current Setting Range Specific range corresponding to "11" code (e.g., likely a low current range such as 0.1A - 0.16A). Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 1000V AC Ambient Temperature Range -20°C to +60°C Standards Compliance IEC/EN 60947-4-1 Mounting Snap-on mounting to compatible Eaton PKZ0 series contactors Auxiliary Contacts 1 NO (95-96) + 1 NC (97-98) Reset Mode Manual reset

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, DILM Series Model Number DILM95-22(RDC24) Rated Operational Current (Ie) 95 A at AC-3, 400V Thermal Current (Ith) 95 A Poles (Main Circuit) 3 (Normally Open) Auxiliary Contacts 2 NO (Normally Open) - Convertible (typical for "-22" variant) Rated Operational Voltage (Ue) Up to 690V AC Control Coil Voltage 24V DC (as specified by RDC24) Utilization Categories AC-3: Squirrel cage motors: Starting, switching off during running AC-1: Non-inductive or slightly inductive loads Motor Rating (at 400V AC) 45 kW / 60 HP Mechanical Life ~ 10 million operations Electrical Life (AC-3) ~ 1 million operations Mounting Standard 35mm DIN Rail (EN 60715) or screw mounting Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Terminal Type Screw Clamp

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, T5B Series Model Number T5B-4-15682/I4/SVB Rated Operational Current (Ie) 125 A (at AC-23) Number of Poles 4-Pole (3 phases + neutral) Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Rated Impulse Withstand Voltage (Uimp) 8 kV Utilization Categories AC-22 (Switching mixed resistive and inductive loads) AC-23 (Switching motor loads) Breaking Capacity Typically 30 kA (at 400V AC) Auxiliary Contacts I4 - Specific auxiliary contact configuration (e.g., 2 NO + 2 NC) Terminal Type SVB - Shrouded Terminal Barrier for enhanced safety Operation Type Rotary Handle Operation Mechanical Life ~ 10,000 operations Electrical Life ~ 1,500 operations (at rated current) Mounting Panel Mount Standards Compliance IEC/EN 60947-3

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, P3 Series Model Number P3-100/I5/SVB Rated Current (In) 100 A Number of Poles 3-Pole Rated Operational Voltage (Ue) 400/415V AC (Three-Phase) Rated Insulation Voltage (Ui) 500V AC Breaking Capacity (Icn) Typically 10 kA (Please confirm with specific catalog) Tripping Characteristic Type C or Type D (Please confirm with specific catalog) Auxiliary Contact I5 - Auxiliary Contact Configuration (e.g., 1 NO + 1 NC contact for remote signaling) Terminal Type SVB - Shrouded Terminal Barrier (Finger Protection) Mounting Standard 35mm DIN Rail (EN 60715) Standards Compliance IEC/EN 60898-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, P1 Series (Domae) Model Number P1-25/I2/SVB25A Rated Current (In) 25 A Number of Poles 1-Pole Rated Operational Voltage (Ue) 230V AC (Single-Phase) Rated Insulation Voltage (Ui) 400V AC Breaking Capacity (Icn) Typically 6 kA / 10 kA (Please confirm with specific catalog) Tripping Characteristic Type C (Instantaneous trip: 5-10 x In) Auxiliary Contact I2 - Auxiliary Contact Configuration (e.g., 1 Normally Open (NO) contact for remote signaling) Terminal Type SVB - Shrouded Terminal Barrier (Finger Protection) Mounting Standard 35mm DIN Rail (EN 60715) Standards Compliance IEC/EN 60898-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, MFD Series Model Number MFD-CP4 Power Supply Voltage 24V DC (Typical for "C" variant) Output Relay DPDT (2 CO) - 2 Changeover contacts Contact Rating: Typically 8A @ 250V AC Timing Ranges Multiple ranges selectable (e.g., from 0.1 seconds up to 100 hours) Functions Multiple timing functions selectable (e.g., On-delay, Off-delay, Interval, Flasher, etc.) Accuracy ±0.5% of set time ± 20 ms Mounting DIN Rail (35mm) Display / Indication Digital Display and LED Status Indicators Standards Compliance IEC/EN 61812-1, UL 508, CSA C22.2 No. 14
