Key Parameters Category Description / Value Product Line Eaton EASY (Smart Relays) Series EASY800 Model / CPU EASY820 Power Supply DC (Typical rating: 24 V DC. Must be verified on the device). Digital Inputs 12 Digital Outputs 8 (Relay Contacts - as indicated by "RC"). Output Type Relay (Electromechanical) - Can switch AC or DC loads within rating. Programming Via EASY-SOFT software or directly on the device using the built-in display and buttons. Display Integrated LCD for showing values, status, and messages. Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Communication Optional communication modules (e.g., for Ethernet, AS-Interface, IO-Link) can be added.

Key Parameters Category Description / Value Product Line Eaton EASY (Smart Relays) Series EASY800 Model / CPU EASY819 Power Supply AC (Common ratings: 120V AC or 230V AC. Must be verified on the device). Digital Inputs 12 Digital Outputs 8 (Relay Contacts - as indicated by "RC"). Output Type Relay (Electromechanical) - Can switch AC or DC loads within rating. Programming Via EASY-SOFT software or directly on the device using the built-in display and buttons. Display Integrated LCD for showing values, status, and messages. Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Communication Optional communication modules (e.g., for Ethernet, AS-Interface, IO-Link) can be added.

Key Parameters Category Description / Value Product Line Eaton EASY Expansion Modules Compatible Controllers EASY800 Series Base Units (e.g., EASY819, EASY820) Module Type Digital I/O Expansion Module Power Supply AC (Common ratings: 120V AC or 230V AC. Must be verified on the device). Total I/O Points 16 Digital Inputs 8 Digital Outputs 8 (Relay Contacts) Output Type Relay (Electromechanical) - Can switch AC or DC loads within rating. Connection to Base Unit Via a flat ribbon cable (usually included). Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail).

Key Parameters Category Description / Value Product Line Eaton NZM4 Model / Frame Size NZM4-XKM2 Release Type Electronic Trip Unit (as indicated by "S") - Adjustable protection settings. Rated Current (Iₙ) 1250 A (This is the frame rating. The operational current can be set within a range on the electronic trip unit). Poles 3-Pole & 4-Pole versions are available. Rated Operational Voltage (Uₑ) Up to 690 V AC, 50/60 Hz Rated Insulation Voltage (Uᵢ) 1000 V Rated Ultimate Short-Circuit Breaking Capacity (Iᶜᵘ) Very high, typically 100 kA or more at 400V AC (IEC 60947-2). The exact value must be verified from the technical data sheet. Trip Unit Functions • Long-time Delay (L) • Short-time Delay (S) • Instantaneous (I) • Ground-fault (G) protection (depending on the specific "S" variant). Mounting Fixed Mounting (for bolted installation in panels) or Draw-out Version (available as an option). Connection Primary power connections are typically made via busbars. Standards Compliance IEC/EN 60947-2 Auxiliary Contacts & Accessories Compatible with the full range of NZM4 accessories, such as auxiliary contacts, undervoltage release, shunt trip, and motor operator.

Key Parameters Category Description / Value Product Line Eaton PKZ (Equipment Protectors) Model / Frame Size PKZMC Rated Current (Iₙ) 1.6 A (This is the fixed rated current for this specific device). Poles 1-Pole, 2-Pole, 3-Pole, and 4-Pole versions are available. Rated Operational Voltage (Uₑ) 400/690 V AC Tripping Characteristic C-Curve (Moderate inrush current tolerance, typically 5-10 x Iₙ). Breaking Capacity Typically high, up to 100 kA at 400V AC (IEC 60947-2), thanks to its current-limiting design. Standards Compliance IEC/EN 60947-2 Mounting Snap-on mounting on 35 mm top-hat rail (DIN rail). Connection Cage Clamp terminal technology for easy, tool-free wiring. Auxiliary Contacts Available as snap-on modules (e.g., PKZMC-AX) to provide signaling (e.g., trip indication). Control Function Manual ON/OFF switching with a toggle handle. Can be padlocked in the OFF position.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM250 Rated Operational Current (Iₑ) at AC-3 250 A (For squirrel-cage motors) Rated Operational Power at AC-3 ~ 132 kW / 177 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 300 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is configurable. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors AC-1: Non-inductive loads Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Integrated Adapter RA250 adapter pre-mounted, enabling quick installation of RCU250 modules. Electrical Durability Hundreds of thousands of operations (load-dependent) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM225A Rated Operational Current (Iₑ) at AC-3 225 A (For squirrel-cage motors) Rated Operational Power at AC-3 ~ 110 kW / 150 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 300 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is configurable. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors AC-1: Non-inductive loads Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Integrated Adapter RAC440 adapter pre-mounted, enabling quick installation of RCM440 modules. Electrical Durability Hundreds of thousands of operations (load-dependent) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM225A Rated Operational Current (Iₑ) at AC-3 225 A (For squirrel-cage motors) Rated Operational Power at AC-3 ~ 110 kW / 150 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 300 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is configurable. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors AC-1: Non-inductive loads Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Integrated Adapter RAC500 adapter pre-mounted, enabling quick installation of RCA/RCM500 modules. Electrical Durability Hundreds of thousands of operations (load-dependent) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM225A Rated Operational Current (Iₑ) at AC-3 225 A (For squirrel-cage motors) Rated Operational Power at AC-3 ~ 110 kW / 150 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 300 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is configurable. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors AC-1: Non-inductive loads Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Integrated Adapter RDC240 adapter pre-mounted, enabling quick installation of RCM240 modules. Electrical Durability Hundreds of thousands of operations (load-dependent) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.

Key Parameters Category Description / Value Product Line Eaton DILM Model / Frame Size DILM250 Rated Operational Current (Iₑ) at AC-3 250 A (For squirrel-cage motors) Rated Operational Power at AC-3 ~ 132 kW / 177 HP at 400V 50Hz Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz Rated Thermal Current (Iᵼₕ) 300 A Poles 3 (Main Contacts) Coil Control Voltage Standard factory setting is often 400V/500V AC. However, this is configurable. The exact voltage must be confirmed by the order code sticker on the device itself. Utilization Categories AC-3: Squirrel-cage motors AC-1: Non-inductive loads Standard Auxiliary Contacts 2 normally open (NO) contacts (as indicated by "/22") Integrated Adapter RAC500 adapter pre-mounted, enabling quick installation of RCA/RCM500 modules. Electrical Durability Hundreds of thousands of operations (load-dependent) Mechanical Durability Millions of operations Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 Mounting Screw mounting via integrated feet or mounting plate. Connection Large screw terminals for main power connections.
