The ABB BC810K02 process control module is engineered for precise and efficient control in demanding industrial environments. It ensures reliable performance across various applications, enhancing operational efficiency.

Core Specifications
1. Drive Unit (ACS800-04-0400-3)

Power Rating: 400kW (536HP)

Output Current: 578A

Input Voltage: 380-480V AC (±10%), 3-phase

Control Technology: Direct Torque Control (DTC)

Efficiency: >97.5%

Enclosure: IP00 (requires P901 cabinet)

2. P901 Cabinet Kit

Material: Powder-coated steel

Mounting: Floor-standing or wall-mounted

Cooling: Forced ventilation (fans included)

Protection Class: IP21 with cabinet

Cable Entry: Bottom/top (configurable)

Key Features
✔ Plug-and-Play Installation - Pre-configured mounting solution
✔ Optimized Airflow - Intelligent thermal management
✔ Service-Friendly - Front-access design
✔ Vibration-Resistant - Industrial-grade construction

Certifications
CE, UL, cUL

EN 61800-3 (EMC)

RoHS compliant

The Altivar 71 ATV71HC40N4 is a 4 kW (5.5 HP) variable frequency drive designed for controlling three-phase motors in industrial applications. It operates with 380V-480V input and provides an output frequency range of 0-590 Hz. The drive supports V/f and Sensorless Vector control, and is ideal for pumps, fans, and conveyors. It features an LED keypad for easy setup and diagnostics and offers Modbus RTU communication with optional protocols like Profibus.
