Technical Parameters Parameter Category Description / Value Brand & Series Eaton, CBL Series Model Number CBLPFW Product Type Power Line Filter Rated Current Specific amperage rating (to be verified from datasheet) Rated Voltage 120/250V AC (Typical for this series) Frequency Range 50/60 Hz (Operation) 0.15-30 MHz (Noise suppression range) Insertion Loss High performance across specified frequency range Leakage Current < 0.5-5 mA (Typical range, specific value depends on model) Safety Standards UL 1283, CSA C22.2 No. 8, IEC 60939 Mounting Panel Mount or Chassis Mount Terminal Type Screw terminals or Quick-connect terminals Operating Temperature -25°C to +85°C (Typical)

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, NZM Series Model Number NZMN1-A160 Rated Current 160 A (Frame Size) Poles Typically 3-Pole (Pole configuration may vary, confirm with specific order code) Rated Operational Voltage (Ue) Up to 690V AC Rated Insulation Voltage (Ui) 800V AC Trip Unit Type Type A - Adjustable Electronic Trip Unit Protection Functions L - Long-time Delay (Overload) S - Short-time Delay (Short-Circuit) I - Instantaneous (Short-Circuit) Breaking Capacity (Icu) High interrupting capacity (Typically 25 kA to 50 kA depending on specific voltage rating) Standards Compliance IEC 60947-2

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PKZM0 Series Model Number PKZM0-4 Rated Operational Current (Ie) 4 A Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Utilization Category AC-3 (Squirrel cage motor: Starting, switching off during running) Motor Power Rating (at 400V AC) 1.5 kW / 2 HP (Approximate) Short-Circuit Breaking Capacity (Icu) Typically 6 kA or higher at 400V AC (Confirm with datasheet) Trip Class Class 10 Operation Type Manual (Toggle Handle) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-4-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PKZM0 Series Model Number PKZM0-6.3 Rated Operational Current (Ie) 6.3 A Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Utilization Category AC-3 (Squirrel cage motor: Starting, switching off during running) Motor Power Rating (at 400V AC) ~2.2 kW / 3 HP (Approximate) Short-Circuit Breaking Capacity (Icu) Typically 6 kA or higher at 400V AC (Confirm with datasheet) Trip Class Class 10 Operation Type Manual (Toggle Handle) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-4-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, PKZM0 Series Model Number PKZM0-32 Rated Operational Current (Ie) 32 A Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Utilization Category AC-3 (Squirrel cage motor: Starting, switching off during running) Motor Power Rating (at 400V AC) ~15 kW / 20 HP (Approximate) Short-Circuit Breaking Capacity (Icu) Typically 6 kA or higher at 400V AC (Confirm with datasheet) Trip Class Class 10 Operation Type Manual (Toggle Handle) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-4-1

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, MFD Series Model Number MFD-CP8-NT Power Supply Voltage 24V DC (Typical for "C" variant) Output Relay DPDT (2 CO) - 2 Changeover contacts Contact Rating: Typically 8A @ 250V AC Timing Ranges Multiple ranges selectable (e.g., from 0.1 seconds up to 100 hours) Functions Multiple timing functions selectable (e.g., On-delay, Off-delay, Interval, Flasher, etc.) Accuracy ±0.5% of set time ± 20 ms Mounting DIN Rail (35mm) Display / Indication Digital Display and LED Status Indicators Standards Compliance IEC/EN 61812-1, UL 508, CSA C22.2 No. 14

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, T3 Series Model Number T3-4-15682/I2/SVB Rated Operational Current (Ie) 63 A (at AC-23) Number of Poles 4-Pole (3 phases + neutral) Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Rated Impulse Withstand Voltage (Uimp) 8 kV Utilization Categories AC-22 (Switching mixed resistive and inductive loads) AC-23 (Switching motor loads) Breaking Capacity Typically 30 kA (at 400V AC) Auxiliary Contacts I2 - Specific auxiliary contact configuration (e.g., 1 NO + 1 NC) Terminal Type SVB - Shrouded Terminal Barrier for enhanced safety Operation Type Rotary Handle Operation Mechanical Life ~ 20,000 operations Electrical Life ~ 5,000 operations (at rated current) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-3

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, T0 Series Model Number T0-3-15680/11/SVB Rated Operational Current (Ie) 63 A (at AC-23) Number of Poles 3-Pole Rated Operational Voltage (Ue) 690V AC Rated Insulation Voltage (Ui) 750V AC Rated Impulse Withstand Voltage (Uimp) 8 kV Utilization Categories AC-22 (Switching mixed resistive and inductive loads) AC-23 (Switching motor loads) Breaking Capacity Typically 30 kA (at 400V AC) Auxiliary Contacts 11 - Specific auxiliary contact configuration (e.g., 1 NO contact) Terminal Type SVB - Shrouded Terminal Barrier for enhanced safety Operation Type Rotary Handle Operation Mechanical Life ~ 20,000 operations Electrical Life ~ 5,000 operations (at rated current) Mounting DIN Rail (35mm) Standards Compliance IEC/EN 60947-3

Technical Parameters Parameter Category Description / Value Brand & Series Eaton, P3 Series Model Number P3-63/EA/SVB/NL Rated Current (In) 63 A Number of Poles 3-Pole Rated Operational Voltage (Ue) 400/415V AC (Three-Phase) Rated Insulation Voltage (Ui) 500V AC Breaking Capacity (Icn) Typically 10 kA (Please confirm with specific catalog) Tripping Characteristic Type C (Instantaneous trip: 5-10 x In) Auxiliary Function EA - Alarm Switch (Signals trip condition via a separate contact) Terminal Type SVB - Shrouded Terminal Barrier (Finger Protection) Variant NL - Specific variant or regional designation (e.g., for Netherlands market or specific certification) Mounting Standard 35mm DIN Rail (EN 60715) Standards Compliance IEC/EN 60898-1

Technical Parameters Category Parameter Specification Input Characteristics Input Voltage 100 - 240 VAC (Wide Range, Auto-Sensing) Input Frequency 50 / 60 Hz Input Current Max. 0.7 A @ 100 VAC Inrush Current Limiting Yes (NTC Thermistor) Output Characteristics Output Voltage 12 V DC Voltage Adjustment Range ~11 - 13.2 V DC (via potentiometer) Rated Output Current 2.1 A Rated Output Power 25 W Efficiency Typically > 80% Ripple and Noise < 150 mVpp (typical) Line Regulation < 1.0% Load Regulation < 1.0% Protection & Safety Overload Protection Electronic, auto-recovery (105% - 150% of Iout) Overvoltage Protection Electronic, auto-recovery Standards CE Marked Environmental & Mechanical Operating Temperature -25 °C to +70 °C (with derating above 50-60°C) Storage Temperature -40 °C to +85 °C Cooling Method Fanless (Convection) Mounting Standard 35 mm DIN Rail Enclosure Protection IP20 (Terminal Protection) Connections Screw Terminals
