FISHER DVC6015
Technical Parameters
Category Parameter Specification / Description
General Model DVC6015
Type Digital Valve Controller (Single-Action)
Product Family FIELDVUE
Primary Protocol HART
Input & Output Input Signal 4 to 20 mA DC, two-wire
Supply Pressure Up to 150 psig (10.3 bar)
Output Action Single-Action (One output port for spring-return actuators)
Performance Linearity ±0.5% of span
Hysteresis Less than 0.4% of span
Air Consumption Steady State: ~0.04 SCFM (1.1 NLPM)
Environmental Ambient Temperature -40°F to 185°F (-40°C to 85°C)
Enclosure Rating Type 4X, 6 (IP66/67); Dust-tight and protected against water.
Hazardous Area Certifications FM/CSA: Explosion-proof, Intrinsically Safe (Class I, II, III, Div. 1 & 2)
ATEX/IECEx: Ex db, Ex tb, Ex ia [ia] (Zone 1 & 21)
Physical Conduit Openings Two 1/2" NPT
Pneumatic Connections Supply & Output: 1/4" NPT
UT150-RN/RET
The Yokogawa UT150 is a compact digital indicating controller designed for precise temperature and process control. With its 1/16 DIN size, the UT150 provides high reliability, fast response, and easy operation. The UT150-RN/RET variant is configured for reliable control applications with standard relay or retransmission outputs. Its compact design, bright LED display, and flexible I/O options make it suitable for a wide range of industrial temperature and process control systems.
