FC-SSWM01 - Industrial 4-in-1 water quality sensor measuring turbidity (0-1000 NTU), residual chlorine (0-5 mg/L), pH (0-14), and conductivity (0-2000 μS/cm). Features Modbus RS-485 output and IP68 waterproof housing for continuous monitoring in harsh environments.

The Schneider LXM23DU10M3X Servo Drive is designed for high-precision control in industrial automation applications, featuring advanced motion control algorithms and robust performance.

Technical Parameters Parameter Specification Model BZMU1N-3-EX160 Rated Current (Iₙ) 160 A Frame Size 160 A Number of Poles 3P (Three Pole) Rated Voltage (Uₑ) 690 V AC Rated Frequency 50/60 Hz Breaking Capacity 35 kA (at 480 V AC) Trip Unit Type Electronic (EX type) Rated Insulation Voltage (Uᵢ) 1000 V Rated Impulse Voltage (Uᵢₘₚ) 12 kV Protection Functions Long-time (L), Short-time (S), Instantaneous (I), Ground Fault (G) Communication Protocol Modbus, Profibus (optional) Mounting Fixed Type Terminal Type Screw Clamp Wire Range 1/0 AWG - 250 kcmil Standards & Approvals UL 489, IEC 60947-2, CSA C22.2
