Core Specifications
Drive Unit (ACS800-01-0003-3):

Output Power: 2.2kW (3HP) at 400V

Output Current: 5.5A continuous

Input Voltage: 3-phase 380-480V AC (±10%)

Overload Capacity: 150% for 60 seconds

Control Technology: Direct Torque Control (DTC)

Efficiency: >96% at full load

Switching Frequency: 1-16kHz (adjustable)

P901 Control Panel:

7" high-resolution color touchscreen

Multi-language interface (12 languages)

Integrated web server functionality

8GB data logging capacity

USB 3.0 configuration port

Real-time clock with battery backup

Key System Features
Advanced Control:
✔ Precision Regulation: ±0.2% speed accuracy
✔ Application Macros: 6 pre-programmed configurations
✔ Process Control: Single PID controller with auto-tuning
✔ Energy Optimization: Power consumption monitoring

Connectivity:

Standard Interfaces:

Modbus RTU (RS485)

Ethernet

Optional Modules:

PROFIBUS DP

PROFINET IRT

DeviceNet

Safety Systems:

Safe Torque Off (STO) - SIL3 certified

Motor thermal protection

Short-circuit protection

Phase loss detection

Mechanical Specifications
Enclosure Rating: IP21 (NEMA 1)

Dimensions: 200 × 400 × 180mm (W×H×D)

Weight: 8.5kg (complete system)

Cooling: Natural convection

Noise Level: <55dB at 1m
