S811+T30N3S
Parameter Specification
Product Series Eaton PowerXL DG1 (S811 Line)
Model Number S811+T30N3S
Description Variable Frequency Drive, 59A, 30kW, 400V
Rated Input Voltage 380 - 480V AC, 3-Phase, 50/60 Hz
Rated Output Current 59 A
Motor Power Rating 30 kW (40 HP) @ 400V
Overload Capacity 150% of rated current for 60 seconds
Control Methods V/F Control, Sensorless Vector Control, Closed Loop Vector Control (with encoder option)
Integrated Features DC Bus Choke (Standard), EMC Filter (Standard), Removable Graphic Keypad
Digital Inputs 4 (programmable)
Digital Outputs 2 (1 relay, 1 transistor)
Analog Inputs 2 (0/4-20mA or 0-10V, programmable)
Analog Output 1 (0/4-20mA or 0-10V, programmable)
Communication Protocols Modbus RTU (standard). Optional fieldbus cards (e.g., Profibus DP, DeviceNet, EtherNet/IP, PROFINET)
Enclosure Rating IP20 / UL Type Open (Designed for mounting inside a control panel)
Standards & Certifications CE, cULus, RoHS
