TRS 120VUC 2CO AU | SIL3 Safety Relay Module

Key Features:

2NO/2NC Safety Contacts (3A, 250V AC)

24V DC Supply (19.2-28.8V)

Dual-Channel Input with cross-monitoring

SIL3/PL e Certified (IEC 61508/ISO 13849-1)

Safety Protections:
✔ Short-circuit proof
✔ Forced-guided contacts
✔ <20ms response time

Industrial Design:

DIN-rail mountable (IP20)

-25°C to +60°C operation

Certified: TÜV, CE, UL

Applications:
✔ Emergency stop systems
✔ Safety gate monitoring
✔ Machine interlocking

→ Reliable safety control for critical applications

(AU variant includes auxiliary PNP output)

IE-CD-V14MRJ/VAPM24V-FJ | Industrial M12-to-RJ45 Adapter (PoE+)

Key Features:

M12 (4-pin D-coded) ↔ RJ45 Conversion

24V PoE+ Support (IEEE 802.3at)

Gigabit Speed (10/100/1000Mbps)

IP67/IP69K Zinc Alloy Housing

Industrial Tough:
✔ -40°C to +75°C operation
✔ Vibration/shock resistant
✔ PG11/M16 cable gland

Certifications:

UL 2238, IEC 61076-2-101

RoHS/REACH

Applications:
✔ Mobile robotics
✔ Washdown environments
✔ Outdoor PoE cameras

→ Seamless Ethernet/PoE connectivity in harsh conditions

*(Non-PoE version available as IE-CD-V14MRJ)*

PRO INSTA 30W 24V 1.3A (2580190000) | Compact DIN-Rail Power Supply

Key Features:

30W Output (24V DC, 1.3A)

Universal Input 100-240V AC

Fanless Design for silent operation

Efficiency ≥88%

Protections:
✔ Overload/Short-circuit
✔ Overvoltage

Compact Design:

Ultra-slim 22.5mm width

DIN-rail mountable (IP20)

-25°C to +70°C operation

Certifications:

UL 508, EN 62368-1

CE, RoHS

Applications:
✔ Sensor/actuator power
✔ Control panel circuits
✔ Low-power automation

→ Space-saving power for small-scale installations

(Ideal for cabinet retrofits - no DC input option)

Weidmüller CP SNT 500W 24V 50A (8778870000)

Key Features:

500W Output (24V DC, 50A)

Wide Input Range 100-240V AC / 125-370V DC

High Efficiency ≥92%

Smart Cooling Temperature-controlled fan

Protections:
✔ Overload/Short-circuit
✔ Overvoltage/Overtemperature

Industrial Design:

Metal housing, IP20

DIN-rail mountable

-25°C to +70°C operation

Certifications:

UL 508, EN 62368-1

CE, RoHS

Applications:
✔ High-power control cabinets
✔ Industrial machinery
✔ Test systems

→ Reliable high-current power for industrial use

(Parallel operation supported for redundancy)

UR20-16DO-P (1315250000) | 16-Channel Digital Output Module

Key Features:

16× PNP Outputs (24V DC, 0.5A/ch)

PROFIBUS-DP Interface (12Mbps)

500V Isolation & Short-Circuit Protection

Compact Design: DIN-rail mountable (IP20)

Industrial Ready:
✔ -25°C to +60°C operation
✔ Per-channel status LEDs
✔ Plug-and-play GSD configuration

Certified: CE, UL, PROFIBUS compliant

Applications:
✔ Factory automation
✔ Motor/valve control
✔ Material handling systems

→ High-density output for industrial control

*(Optional: High-current 1A/ch version available)*

Weidmüller UR20-FBC-PB-DP PLC Set (1334870000)

Complete Package Includes:

1× PLC Base Unit

PROFIBUS-DP & RS-485

24V DC power, -25°C to +60°C

5× 8DI-P Modules (8ch PNP inputs, 24V DC)

5× 4DO-P Modules (4ch PNP outputs, 0.5A/ch)

Key Features:
✔ Modular DIN-rail system (IP20)
✔ Real-time diagnostics with LED indicators
✔ Expandable to 32 modules

Applications:
✔ Machine control
✔ Process automation
✔ Data logging systems

Certified: CE, UL, RoHS

→ Ready-to-deploy industrial control solution

(Other protocols available: PROFINET/Ethernet versions on request)

PRO MAX 120W 24V 5A (1478110000) | Industrial DC Power Supply

Key Features:

120W Output (24V DC, 5A)

Wide Input Range 85-264V AC / 120-370V DC

High Efficiency ≥94% (Active PFC)

Smart Cooling Temperature-controlled fan

Protections:
✔ Overload/Short-circuit
✔ Overvoltage/Overtemperature

Industrial Design:

Metal housing, IP20

DIN-rail mountable

-30°C to +70°C operation

Certifications:

UL 508, EN 62368-1

CE, RoHS

Applications:
✔ Control cabinets
✔ Automation systems
✔ Test equipment

→ Reliable power for critical industrial applications

*(Adjustable output: 22-28V via potentiometer)*

SCS 24VDC P1SIL3DS (1303890000) | SIL3 Safety Control Switch

Key Features:

24V DC power input (20-30V range)

Dual safety relays (6A/250V AC, DPST-NO)

SIL3/PL e certified (IEC 61508/ISO 13849-1)

ESPE input for safety devices (e.g., light curtains)

Safety Ready:
✔ Forced-guided contacts
✔ Cross-circuit detection
✔ Manual reset option

Robust Design:

IP65 front / IP20 terminals

-25°C to +60°C operation

Certified: CE, UL, TÜV

Applications:
✔ Emergency stop circuits
✔ Robotic safety systems
✔ Hazardous machinery guards

→ High-reliability protection for critical operations

(Optional ATEX version available for explosive environments)

IE-CST (9204350000) | Industrial Ethernet Cable Tester

Key Features:

Fast Diagnostics: Detects opens/shorts/miswires

PoE Check: Tests 802.3af/at/bt compliance

Length Measurement: Up to 150m

Rugged Design: IP40 rated, -10°C to +50°C

Industrial Ready:
✔ M12 adapter compatible
✔ Backlit LCD display
✔ 20+ hour battery life

Certifications: CE, FCC, RoHS

Applications:
✔ PROFINET/Ethernet installation
✔ Switch cabinet maintenance
✔ Field network troubleshooting

→ Your go-to tool for reliable industrial cabling

(Optional: DIN-rail mount kit available)

PRO ECO3 120W 24V 5A (1469530000) | Industrial Power Supply

Key Features:

120W Output (24V DC, 5A)

Universal Input 85-264V AC / 120-370V DC

High Efficiency 93% (Active PFC)

Full Protections OVP/OCP/SCP/OTP

Fanless Design for silent operation

Industrial Ready:
✔ -25°C to +70°C operation
✔ Metal housing, IP20 rated
✔ DIN-rail mountable

Certifications:

UL 508, EN 62368-1

CE, RoHS compliant

Applications:
✔ Control panels
✔ Sensor networks
✔ Light industrial systems

→ Compact power solution for reliable automation

*(Adjustable output: 22-28V via potentiometer)*
