DILM225-XSL
Key Parameters
Category Description / Value
Product Line Eaton DILM
Model / Frame Size DILM225
Rated Operational Current (Iₑ) at AC-3 225 A (For squirrel-cage motors: Starting, switching off during running)
Rated Operational Power at AC-3 ~ 110 kW / 150 HP at 400V 50Hz
Rated Operational Voltage (Uₑ) Up to 1000 V AC, 50/60 Hz
Rated Thermal Current (Iᵼₕ) 300 A
Poles 3 (Main Contacts)
Coil Control Voltage DC - The specific voltage (e.g., 24V, 48V, 110V, 220V DC) must be confirmed by the order code sticker on the device itself. The "L" suffix is consistent with a DC coil.
Utilization Categories AC-3: Squirrel-cage motors (starting, switching off during running)
AC-1: Non-inductive or slightly inductive loads
Arc Extinction System Sintered metal arc chute (as indicated by "S")
Electrical Durability Hundreds of thousands of operations (dependent on load)
Mechanical Durability Millions of operations
Standards Compliance IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14
Mounting Screw mounting via integrated feet or mounting plate.
Connection Large screw terminals for main power connections.
Auxiliary Contacts Typically, auxiliary contact blocks (e.g., DILEM...) are available as add-on accessories and can be mounted on the front.
PRO MAX 120W 24V 10A 1478230000
Weidmüller PRO MAX 120W 24V 10A (1478230000)
Key Features:
120W Output (24V DC, 10A)
Wide Input Range 85-264V AC / 120-370V DC
High Efficiency ≥94% (Active PFC)
Protections:
✔ Overload/Short-circuit
✔ Overvoltage/Overtemperature
Industrial Design:
Metal housing, IP20
DIN-rail mountable
-30°C to +70°C operation
Certifications:
UL 508, EN 62368-1
CE, RoHS
Applications:
✔ Control panels
✔ Sensor networks
✔ Industrial automation
→ Compact power for demanding applications
*(Output adjustable: 22-28V via potentiometer)*
