5180SF-1213A0R Pressure Sensor - Product Brief
Core Description:
The 5180SF-1213A0R is a stainless steel pressure sensor designed for harsh industrial environments. With ±0.5% FS accuracy and 0.5-4.5V ratiometric output, it provides reliable 0-12 psi measurement for fluids and gases.

Key Features:
✔ Robust Construction

17-4PH stainless steel wetted parts

IP65 protection

-40°C to +125°C operation

✔ Precision Performance

<2ms response time

Temperature compensated

3x burst pressure rating

✔ Easy Integration

1/4" NPT process connection

5V DC powered

Reverse polarity protection

Typical Applications:
• Hydraulic system monitoring
• Compressed air control
• Medical equipment
• Process automation

Certifications:
RoHS, REACH compliant

Model Options:

D0R: Digital I²C output

EX: ATEX certified version

Technical Advantages:
→ Laser-welded stainless steel
→ NIST-traceable calibration
→ 24-month warranty

DC1010CL-700000-E Encoder - Product Brief
Core Description:
The DC1010CL-700000-E is a 700k PPR hollow-shaft encoder delivering ±1 arc-second accuracy for ultra-precise motion control applications.

Key Features:
✔ Ultra-High Resolution

700,000 pulses/revolution

30-bit multi-turn absolute

10,000 RPM max speed

✔ Industrial Robustness

10mm hollow shaft

IP65 aluminum housing

-40°C to +100°C operation

✔ Advanced Interface

Differential RS422 output

Optional SSI/BiSS-C

Onboard diagnostics

Typical Applications:
• High-end CNC rotary axes
• Astronomical equipment
• Robotics precision joints
• Semiconductor wafer stages

Certifications:
CE, RoHS, EN 61800-5-1

Model Options:

EX: Hazardous area version

HT: Extended temperature

Technical Advantages:
→ 100G shock resistance
→ Zero-position retention
→ 5-year warranty

VUQUEST3310G Vision Sensor - Product Brief
Core Description:
The VUQUEST3310G is a 5MP smart vision sensor combining ±0.05% measurement accuracy with AI-based defect detection for automated quality control.

Key Features:
✔ Precision Imaging

30 fps @ 5MP resolution

0.05mm feature detection

Integrated RGB lighting

✔ Industrial AI

Pre-trained defect models

Edge computing capability

No PC required

✔ Rugged Design

IP67 aluminum housing

GigE PoE+ connectivity

4x DI/2x DO

Typical Applications:
• Electronics assembly
• Automotive welding inspection
• Food packaging seal check
• Medical device verification

Certifications:
CE, RoHS, FCC

Model Options:

HR: 10MP high-resolution

EX: Explosion-proof

Technical Advantages:
→ 3D measurement mode
→ Multi-sensor sync
→ 36-month warranty

TB1 Industrial Sensor - Technical Specifications
1. General Information
Model Number: TB1

Product Type: Temperature & Humidity Transmitter

Design Purpose: Environmental monitoring in industrial facilities

2. Key Performance Parameters
Temperature Range: -40°C to +85°C

Accuracy: ±0.3°C (temperature), ±2% RH (humidity)

Response Time: <15s (temperature), <30s (humidity)

Output Resolution: 0.1°C / 0.1% RH

3. Electrical Specifications
Power Supply: 24V DC (12-36V range)

Output Signal:

Analog: 4-20mA (dual-channel)

Digital: RS-485 Modbus RTU

Current Consumption: <25mA

4. Mechanical Specifications
Housing Material: ABS+PC (IP65)

Dimensions: 110×80×40mm

Weight: 230g

Mounting: DIN rail or wall mount

5. Environmental Ratings
Operating Range: -40°C to +85°C

Humidity Limits: 0-100% RH (non-condensing)

EMC Immunity: EN 61000-6-2

6. Special Features
Dual parameter measurement

LCD display with backlight

Programmable alarm thresholds

Auto-calibration function

7. Certifications & Compliance
Industry Standards: EN 60751 (Pt100)

Safety: EN 61010-1

Compliance: CE, RoHS

8. Application Scenarios
✔ HVAC system monitoring
✔ Clean room control
✔ Food storage facilities
✔ Pharmaceutical production

9. Model Variations
TB1-P: PoE version

TB1-W: Wireless (LoRaWAN)

TB1-EX: Hazardous area

10. Technical Notes
Includes NIST-traceable certificate

36-month warranty

Custom parameter sets available

Configuration Options:
[1] Compare with TB2 series
[2] Request API integration guide
[3] Get calibration protocol

Document Status:
Rev 1.5 | 2024-07-15
Specifications subject to change

This specification follows ISO 9001 and EN 60751 standards.

060-B119-05 Pressure Transducer - Product Brief
Core Description:
The 060-B119-05 is a high-precision pressure transducer offering ±0.1% FS accuracy for industrial fluid/gas systems. Available in 0-5V, 0-10V, or 4-20mA outputs, it ensures reliable performance in harsh environments.

Key Features:
✔ Ultra-Precise Measurement

0-100 psi standard range (customizable)

<5ms response time

Temperature compensated

✔ Industrial Durability

316L stainless steel construction

IP67 protection

-40°C to +85°C operation

✔ Flexible Integration

1/4" NPT/G1/4 process connection

Multiple output options

Easy zero/span adjustment

Typical Applications:
• Hydraulic power units
• Compressed air monitoring
• Industrial automation
• Energy recovery systems

Certifications:
CE, RoHS, ASME B40.100

Model Options:

-10: 0-10V output

-20: 4-20mA + HART®

-EX: Hazardous area version

Technical Advantages:
→ 2x overpressure protection
→ NIST-traceable calibration
→ 36-month warranty

AWM5104VN Airflow Sensor - Product Brief
Core Description:
The AWM5104VN is a high-precision mass airflow sensor for 0-200 SCCM applications, featuring ±3% accuracy and bidirectional flow detection. Ideal for medical, HVAC, and industrial gas monitoring.

Key Features:
✔ Precision Measurement

Analog (0.5-4.5V) or digital (I²C) output

<10ms response time

Temperature compensated

✔ Compact & Lightweight

12g thermoplastic housing

3mm barbed fittings

-25°C to +85°C operation

✔ Flexible Integration

Bidirectional flow capability

Low power consumption (<15mA)

Medical-grade options

Typical Applications:
• Medical ventilators
• HVAC damper control
• Gas chromatography
• Industrial leak detection

Certifications:
CE, RoHS, UL 61010-1

Model Options:

-D: I²C digital interface

-H: High-flow (1000 SCCM)

-M: ISO 13485 compliant

Technical Advantages:
→ NIST-traceable calibration
→ Reverse polarity protection
→ 24-month warranty

OH4502-1-1USB Fiber Optic Sensor - Product Brief
Core Description:
The OH4502-1-1USB is a USB-powered fiber optic sensor offering 0.01mm resolution and <0.5ms response time, ideal for precision automation with direct PC integration.

Key Features:
✔ Ultra-Precise Detection

1-100mm adjustable range

Red LED/laser options

1kHz sampling rate

✔ Plug-and-Play USB

No external power needed

OH-Suite Pro software included

Python/C++ API support

✔ Industrial Durability

IP65 aluminum housing

5G vibration resistance

30,000 Lux light immunity

Typical Applications:
• Precision assembly robots
• Laboratory automation
• Microelectronics inspection
• Biomedical device manufacturing

Certifications:
CE, RoHS, EN 60825-1

Model Options:

-L: Laser-enhanced version

-EX: Industrial Ethernet

Technical Advantages:
→ Auto-teach for quick setup
→ Real-time USB data streaming
→ 24-month warranty

022-0902-000 Proximity Sensor - Product Brief
Core Description:
The 022-0902-000 is a rugged 2mm range inductive proximity sensor with PNP NO output, designed for precise metal object detection in industrial automation.

Key Features:
✔ Reliable Detection

±0.02mm Repeatability

500Hz Response Speed

LED Operation Indicator

✔ Industrial Durability

Nickel-Plated Brass Housing

IP67 Protection

-25°C to +70°C Operation

✔ Easy Integration

M12 Threaded Mounting

Short-Circuit Protection

Direct PLC Compatibility

Typical Applications:
• Machine Tool Limit Switches
• Automated Assembly Lines
• Material Handling Systems

Certifications:
CE, RoHS, EN 60947-5-2

Model Options:

NPN Output Version Available

ATEX Certified Variant

Technical Advantages:
→ 5M+ Operation Cycles
→ EMI/RFI Immune Design
→ 36-Month Warranty

HBAC-WIN2P Wireless Sensor - Product Brief
Core Description:
The HBAC-WIN2P is a dual-parameter wireless sensor combining vibration (20g) and temperature (+85°C) monitoring with 5-year battery life for industrial IoT applications.

Key Features:
✔ Wireless Condition Monitoring

Bluetooth 5.0 + LoRaWAN

2km long-range transmission

16MB onboard storage

✔ Industrial Durability

316L stainless steel housing

IP68 submersible rating

Magnetic/threaded mounting

✔ Smart Diagnostics

ISO 10816 vibration standards

Predictive maintenance alerts

Cloud-based analytics

Typical Applications:
• Motor/pump bearing health
• Gearbox vibration analysis
• Conveyor roller monitoring
• HVAC compressor tracking

Certifications:
ATEX Zone 2, FCC, CE

Model Options:

EX: Hazardous area version

HD: High-temperature variant

Technical Advantages:
→ 5-year battery life
→ Dual wireless protocols
→ 36-month warranty

S7820A-1007 Load Cell - Product Brief
Core Description:
The S7820A-1007 is a precision load cell offering ±0.02% FS accuracy for 1007 lb (500 kg) industrial weighing applications, featuring IP68 protection and alloy steel construction.

Key Features:
✔ Ultra-High Accuracy

0.02% FS nonlinearity

<0.02% creep/30min

150% safe overload

✔ Rugged Design

Nickel-plated alloy steel

IP68 submersible rating

-20°C to +70°C operation

✔ Easy Integration

150×150mm platform

4×M10 mounting holes

350Ω bridge configuration

Typical Applications:
• Industrial platform scales
• Tank weighing systems
• Force testing equipment
• Process control batching

Certifications:
OIML R60, CE, RoHS

Model Options:

SS: Stainless steel variant

EX: Hazardous area version

Technical Advantages:
→ 60-month warranty
→ NIST-traceable calibration
→ 5,000MΩ insulation resistance
